Y-T048A Air Hydraulic Coil Spring Compressor

Short Description:

Color: Blue, balck, red , orange or customized

Send email to us

Product Detail

Product Tags

Characteristics

* 1500kg Capacity foot-operated hydraulic unit.

* Quicker and easier than using ratchet driven spring compressor.

* Plastic coated yokes reduce the risk of spring slippage/damage.

* Suitable for springs from Ø102mm to Ø160mm.

* Features a hands Free foot operated hydraulic action with quick release

* Features: smooth, long stroke hydraulic actuator

* Unit includes two sizes of spring yokes: 100mm - 158mm

* Has adjustable spring yokes hold the strut spring very securely

* The upper yoke bracket slide provides multiple height adjustments with 7 height positions

* Securely fitted with Safety Guard

* Is not suitable for some 4WD applications

Technical Specification

Description	Auto Equipment Hand Operated Strut Coil Spring Press Compressor High Speed Tool
Color	Blue, balck, red , orange or customized
Material	Steel
Type	hand tool
Max spring dia	260mm
Max spring height	430mm
Size	3307001120mm
Packaging	680340200mm
N.W. / G.W.	29.5KG / 31KG

Advantages

Direction for use:

The upper and lower pinion hooks are used to fix the upper and lower ends of the springs

Hydraulic spring compressor mainly used to disassembles shock absorption spring for mini-cars and cars. It can compress the spring and stay in any position with hand. Operation simple and fast, safe and reliable.

Maintenance of Shock Absorption Spring Compressor:

1. Lubrication: smear a thin layer of grease in the middle of the pillar to make the pillar lubricated before using.

2. Refuel: make the jack down to the lowest level , remove the oil plug , refuel the oil and make the oil level about 8mm from the oil hole .

Rust Protection: wipe the rusty mark with a linoleum , and make the jack down to the lowest level if don’t use it .
